Enviro 740


Enviro 740


Solid and rugged construction makes it evident that the Enviro 740 is built to last, and with independent triple disc assemblies for maximum ground contact it's excellent for drilling over undulating ground. Adjustable press wheels control the seed depth over the entire sowing width for enhanced soil to seed contact and increased moisture retention to promote germination.

Seed Size

Small to Large

Operation Size

from 100 Ha

Features

  • Independent drag arms with triple discs and press wheels for each row
  • Easy access front and rear loading platforms with safety rails
  • 130mm / 5 1/4" or 150mm / 6" row spacing options
  • Weather skirts cover seed / fertiliser outlets
  • Depth control via the wheel legs and the press wheels
  • Stainless steel agitator shafts in boxes
  • Accurate and reliable gearbox
  • Peg roller seed / fertiliser distribution units
  • Weigh kit with electronic scales and hectaremeter
  • Sows a variety of seeds and fertiliser
  • Free-wheeling hub and safety chains for transport
  • 15/17/19/21/23/26 row models
  • Tractor grip tyres





Quick Specs

Rows15 17 19 21 23 26
Weight (kg) 2730 3080 3485 3850 4200 4725
Sowing width (mm) 2250 2210 2850 2835 3450 3380
Overall width (mm) 3284 3284 3884 3884 4644 4644
Overall length (mm) 3750 3750 3750 3750 3750 3750
Height (mm) 1520 1520 1520 1520 1520 1520
Box capacities (l) 349 349 443 443 538 538
Row spacing (mm) 150 130 150 130 150 130
